Explosives Charging Vehiclesh, It is a new type of vehicle that innovatively develops the BCLH-15 single-sided spiral charging method, which is the first of its kind both internationally and domestically. When the on-site mixed ammonium deep fryer truck is loaded with explosives towards the muzzle, the left and right sides of the vehicle are first unfolded by the spiral. After one side of the spiral is filled with explosives towards the muzzle, the other side of the spiral can be filled into the corresponding muzzle on the other side. This innovative invention mechanism greatly improves the charging efficiency. In the case where the single hole charging efficiency of the BCLH three models is the same, the double-sided spiral model is about 1.5 times more efficient than the single-sided spiral and elevated spiral models for on-site mixed ammonium oil explosive vehicles. Explosions Charging Vehicles greatly shorten the charging time, reduce the working time of workers in harsh outdoor environments, save fuel consumption, and reduce a lot of manpower and material resources, providing a more convenient blasting plan for blasting companies. The company believes that Explosions Charging Vehicles will replace single-sided spiral and elevated spiral on-site mixed ammonium oil explosive vehicles in the future, and have a very broad development prospect.

Key Technical Parameters
Dry cargo hold with an effective volume of 17.3m³ and a loading capacity of 17,000kg
The fuel tank has an effective volume of 1.14m³ and a load capacity of 1000 kg.
Loading efficiency 300-450kg/min
Measurement error ≤ 2%
Dimensions: Length/Width/Height (10490*2460*3792mm)
Total weight 32,000 kg
Ready mass 15000kg
Service
Provide integrated services throughout the entire process from raw material distribution, on-site mixing, to loading and blasting.
01
Process
Using a vehicle mounted intelligent control system, the raw materials are accurately mixed into explosives at the work site.
02
Packaging
The raw materials are stored in dedicated vehicle storage tanks in bulk, without the need for traditional finished explosive packaging.
03
Transportation
Use mixed special vehicles to transport semi-finished raw materials safely and efficiently.
04
Certificate
Patent








Transportation
